Y09-1016 airborne particle counter

Y09-1016 airborne particle counter is a detection instrument used to measure and analyze the size and quantity of dust particles per unit volume of air in clean environments,and to determine the cleanliness level of clean environments based on standards. Widely used for clean room testing in enterprises such as medicine and health,optics,chemistry,food,cosmetics,electronics,biological products,aerospace,etc.

Inquiry Now

Product Description

TECHNICAL FEATURES:

Touch screen control system
M³/ft³unit selection
13.000 sampling data storage
ISO/GMP/209E standard optional
Three-level password management authority
USB export and real-time printing
Count report in accordance with GMP/ISO14644/209EISO21501-4

PERFORMANCE PARAMETERS

sampling flow	2.83L/min
Particle size channel	0.1,0.2,0.3,0.5,1.0,5.0um
Dimensions	310240180mm³(wdh)
Weight	8kg
Sampling period	1s~99 min 99s (adjustable)
Sampling frequency	1~99h 99m 99s
Power supply	14.8V lithium battery
Display	800*480 resolution, 65k colors, touch screen control system
Rated power	20w
Self-cleaning time	≤10min
Light source life	Longlife laser diode with 50,000 hours MTTF
Print mode	Dot matrix printing
Counting alarm	0.1,0.3,0.5,5.0 Alarm data can be set arbitrarily for each channel
Data storage	99999 groups
Continuous working hours	6H
Maximum sampling concentration	35000/L
Working environment	Temperature:10~35℃;Humidity:20%~75%
Optional accessories	SS Auxiliary Vehicle
Processing method	Single,Repeated,Continuous,Calculated,GBmodel(UCL)
